Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: MOKO
  • Model Number: MK60123BJ05
  • Base Material: fr4
  • Copper Thickness: 1oz
  • Board Thickness: 1.6mm
  • Min. Hole Size: 0.25mm
  • Min. Line Width: 0.1mm
  • Min. Line Spacing: 0.1mm
  • Surface Finishing: Hasl lead free
  • Max Panel size: 800*508mm
  • Board finished thickness: 0.2-4.0mm
  • Tolerance of finished panel: ±10%
  • Surface Treating Process of Inner: Brown Oxide
  • Impedence control and tolerance: 50Ω±10%
  • Wrap and twist: ≤0.5%
  • Standard: IPC-A-610D
  • Service type: One-stop turnkey service
  • Item: wifi PCBA
  • PCBA QC: X-ray,AOI Test,Functional test

Packaging & Delivery

Packaging Details: Inner packing:Vacuum Package. Outer packing:High Quality Carton Box
Delivery Detail: PCB:5-7days PCBA:20~25days

Fr4 double-sided GPS Printed Circuit Board

---- Famous for PCBA on GPS module,Medical care devices,Car controller  ,Vending machine controller, etc



Product Description



PCB Technical Specification:

Number of Layer1,2,4 or 6,upto 18 layer
Order Quantity1 to 50,000
Board ShapeRetangular,round,slots,cutouts,complex,irregular
Board TypeRigid, Flexible, Rigid-flexible
Board MaterialFR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.
Board CuttingShear,V-score,Tab-routed
Board Thickness0.2-4.0mm, Flex 0.01-0.25mm
Copper Weight1.0, 1.5, 2.0 oz
Solder MaskDouble-sided green LPI,Also support Red,White,Yellow,Blue,Black
Silk ScreenDouble-sided or single-sided in white,yellow,black,or negative
Silk Screen Min Line Width0.006'' or 0.15mm
Max Board Dimensions20 inch*20inch or 500mm*500mm
Min Trace/Gap0.10mm, or 4mils
Min Drill Hole Diameter0.01'',0.25mm, or 10mils
Surface FinishHASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.
Board Thickness Tolerance±10%
Copper Weight Tolerance± 0.25 oz
Minimal Slot Width0.12'', 3.0mm, or 120mils
V-Score Depth20-25% of board thickness
Design File FormateGerber RS-274,274D,Eagle and AutoCAD's DXF,DWG





PCBA Capabilities:

QuantityPrototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000
Type of AssemblySMT,Thru-hole
Solder TypeWater Soluble Solder Paste,Leaded and Lead-Free
Components

Passive Down to 0201 size

BGA and VFBGA

Leadless Chip Carriers/CSP

Double-sided SMT Assembly

Fine Pitch to 0.8mils

BGA Repair and Reball

Part Removal and Replacement

Bare Board Size

Smallest:0.25*0.25 inches

Largest:20*20 inches

File Formate

Bill of Materials

Gerber files

Pick-N-Place file

Types of ServiceTurn-key,partial turn-key or consignment
Component packagingCut Tape,Tube,Reels,Loose Parts
Turn TimeSame day service to 15 days service
TestingFlying Probe Test,X-ray Inspection AOI Test
PCB assembly process

Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing



Company Information





MOKO TECHNOLOGY LTD was founded in 2001, located in Shenzhen. We mainly offer Electronics Assembly Service. From our ISO9001:2008 certified factory, we turn out up to 10000 square meter of PCBs and 400000 PCBAs monthly. For assembly, utilizing 8 high-speed SMT lines from Yamaha and Sony, to meet customers' need.





MOKO offer PCBA for kickstarters, engineering offices and global elctronic companies.



Our PCBA are apply for medical care devicesvending machineGPS tracker; Smoke alarm; Food detector; Blood pressure instrument; fish finder; communication board and other fields.



Moko atended exhibitions,EXPO Munish 2012,2014; EXPO Moscow 2013,2015; HK Electronic Fairs.



Company Overview:





MOKO service including:

1.PCB fabrication.

2.Turnkey PCBA:PCB+components+SMT and through-hole assembly+enclosure molding&housing.

3.PCB clone:reverse engineering,with all compoents compeleted.



Our advantages:

1.Free programming and free functional test,free package.

2.High quality:IPC-A-610E standard,E-test,X-ray,AOI test,QC,100% functional test.

3.Professional service.ISO SMT adn through hole assembly,over 10 years experience.

4.Certification for electronics:UL,94-V0,CE,SGS,FCC,Rohs,ISO9001:2008,ISO14001

5.Warranty period for PCBA:2 years.




Relating Products Show:



Cooperation:







Packaging & Shipping





Our Services







Shipment ways:



1.Small order: DHL,FEDEX,UPS,TNT,etc.
2.Larger order: By Sea.







 PCB

Single/double side

4 layer

6 layer

Above 8 layer

HDI

Sample lead time(Normal)

5-6

6-7

7-8

10-12

15-20

Sample lead time(Fastest)

48-72 hours

5

6

6-7

12

Mass production lead time(First batch)

7-9

10-12

13-15

16

20

PCB Assembly

  PCB Fab+Components Sourcing+PCBA=20 days





FAQ



Why us?



Quality

Our UL/Rohs standards insure quality assemblies from start to finish. Whether it's a simple custom product or a complex turnkey production run, Moko will adhere to the highest quality standards.



--------------------------------------------------------------------------------



Capable

Moko offers the latest in assembly capabilities and qualifications insuring that quality is built into every product we produce.



--------------------------------------------------------------------------------



Experience

When it comes to your build you want a partner you can depend on. Our management team has over 10years of combined industry knowledge. Our engineering team has over 7 years experience.



--------------------------------------------------------------------------------



Protecting your interests

Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality contract and treat your important documentation as they would their own.



--------------------------------------------------------------------------------



Flexibility

We pride ourselves on our ability to custom tailor programs around our customers' needs. We take time to listen to your unique business needs and then set out to surpass them.



Contact Us



 Should you have any further questions,please feel free to contact us!
